Unable to flash conbee 2 on windows

deCONZ General Support
1

Hi, I can not upgrade my conbee stick

I have downloaded the latest GCFFlasher and latest software but I have this error ‘query bootloader failed’ every time

logs:

GCFFlasher.exe -d COM3 -c -t 100 -f deCONZ_RaspBeeII_0x26780700.bin.GCF
read file success: deCONZ_RaspBeeII_0x26780700.bin.GCF (163244 bytes)
flash firmware
connect \\.\COM3, baudrate 115200
command UART reset done
connect \\.\COM3, baudrate 115200
query bootloader id V3
query bootloader id V3
query bootloader failed
retry: 25 seconds left
read file success: deCONZ_RaspBeeII_0x26780700.bin.GCF (163244 bytes)
flash firmware
command reset timeout
connect \\.\COM3, baudrate 115200
query bootloader id V3
query bootloader id V3
query bootloader failed
retry: 20 seconds left
read file success: deCONZ_RaspBeeII_0x26780700.bin.GCF (163244 bytes)
flash firmware

I don’t have deconz running on this computer but i did try to upgrade the stick from deconz that is running in a VM a couple of times before realizing it could not work.

Any help would be appreciated

2

Hi,
for the usb stick you have to use the firmware for conbee2.
Should be: Index of /deconz-firmware/ → https://deconz.dresden-elektronik.de/deconz-firmware/deCONZ_ConBeeII_0x26780700.bin.GCF

And check the documentation for firmware updating.

3

thanks, i was following some guide and missed it was not the right firmware
