If I add a switch, it turns everything on or off

General
1

Hi everyone, I am using conbee 2 on a nuc with hass os, everything worked fine thill a month ago.
I install some new ZigBee lights controller and a 8 button switch and it also works fine but after that I can not install more switch.
If I add a switch, it turns everything on or off.

In hass community they told me to install more router, like always on things wich i did now but still the same results.

So i can still add light ore power plug and control them with switch i already have, but as soon I install a new switch this new switch will turn all my light and plogs on even if i program it to switch one light.
I do all the program in the poscon addon in hass os

I am ising the ikea switch i already have 4 working fine.

What am I not seeing?

Thanks
Neopegasus

2

Hello, what is the faulty device ?
Can be a natural working mode, during the inclusion deconz deconz need to “disable this feature”.

3

its no faulty device, as soon I add a new switch like the ikea tradfri the switch will turn all my lights off or on, even if i asain a button to a light it still turn avrething of or on.
i already have 4 of touse working i just want to put new extra one

4

So you hava 4 working device but the new one make broadcast command ?
You use the 4 press on the remote for the inclusion ?
Can you make 2 inclusions, without deleting the previous one.

Can you show the device json, visible in phoscon/help/API Information/sensor ?

5
6

I will try it as soon back home, it looks a little difficult on hass os but I think I will find it out.
I will report back.

7

@Mimiix , I try the link , but I don’t see a way to get to that data base as i am running Home assistant OS, when I look at the file system, and try search, I don’t find it ore see what they are talking about zll.db.

I gues is for poaple that use hass.io and not hass.os?
the second option is no option because I need to reprograam every thing as a lot of my automation are make with zigbee…

8

Ok, the device is deleted. if i enter a new one it wil do the same no mather what I do.
do you mean to add it and then show the file?

this is my file:

{
    "6": {
        "config": {
            "alert": "none",
            "battery": 60,
            "group": "6",
            "on": true,
            "reachable": true
        },
        "ep": 1,
        "etag": "eab3e1d989f4fcef1eecd7fbd0c96b34",
        "lastannounced": "2022-02-24T04:32:48Z",
        "lastseen": "2022-02-27T14:54Z",
        "manufacturername": "IKEA of Sweden",
        "mode": 1,
        "modelid": "TRADFRI on/off switch",
        "name": "Switch Kamer",
        "state": {
            "buttonevent": 1002,
            "lastupdated": "2022-02-27T06:24:31.661"
        },
        "swversion": "2.2.010",
        "type": "ZHASwitch",
        "uniqueid": "5c:02:72:ff:fe:3f:85:a5-01-1000"
    },
    "12": {
        "config": {
            "alert": "none",
            "battery": 16,
            "group": "12",
            "on": true,
            "reachable": true
        },
        "ep": 1,
        "etag": "93c2f50e726f29202116f63481a7b23b",
        "lastannounced": "2022-02-21T07:02:33Z",
        "lastseen": "2022-02-27T15:29Z",
        "manufacturername": "IKEA of Sweden",
        "mode": 1,
        "modelid": "TRADFRI on/off switch",
        "name": "Switch Juliana",
        "state": {
            "buttonevent": 2002,
            "lastupdated": "2022-02-26T09:22:41.666"
        },
        "swversion": "2.2.010",
        "type": "ZHASwitch",
        "uniqueid": "b4:e3:f9:ff:fe:58:5f:09-01-1000"
    },
    "13": {
        "config": {
            "alert": "none",
            "battery": 60,
            "group": "13",
            "on": true,
            "reachable": true
        },
        "ep": 1,
        "etag": "bc7fc81b591325ba072f628aca43bf74",
        "lastannounced": "2022-02-12T19:42:56Z",
        "lastseen": "2022-02-27T15:28Z",
        "manufacturername": "IKEA of Sweden",
        "mode": 1,
        "modelid": "TRADFRI on/off switch",
        "name": "Switch David",
        "state": {
            "buttonevent": 2002,
            "lastupdated": "2022-02-24T06:33:21.769"
        },
        "swversion": "2.2.010",
        "type": "ZHASwitch",
        "uniqueid": "b4:e3:f9:ff:fe:58:53:ec-01-1000"
    },
    "17": {
        "config": {
            "battery": 87,
            "group": "6657,6658,6659,6660",
            "on": true,
            "reachable": true
        },
        "ep": 1,
        "etag": "1ae80f040ab218353eb5cd52c7e230c7",
        "lastannounced": "2022-02-03T15:37:40Z",
        "lastseen": "2022-02-27T15:24Z",
        "manufacturername": "EcoDim",
        "mode": 1,
        "modelid": "ED-10014",
        "name": "4-channel remote controller",
        "state": {
            "buttonevent": 2002,
            "lastupdated": "2022-02-27T14:45:21.682"
        },
        "swversion": "2.5.3_r20",
        "type": "ZHASwitch",
        "uniqueid": "60:a4:23:ff:fe:60:e8:61-01-0006"
    }
}

I will keep trying but is strange, I understand the wiki but i dont know how i will do that in the home automation Opereting System.

Best regards

9

It’s in the container. You have to ask this on the ha forum.

10

Thanks for the reply, I did, I will wait for there’s response

11

It’s the device id = 17 that cause issue ? It s not an ikea one ?

12

no, @Smanar , I deleted the one that give me problem , as some of my sigbee do the heating of my aquarium and did not want to have fish soup beacous it turn the heater on of the aquaruim.

In hass forum they advice me to have more router witch i did but still no help.

I am still searching the way to fix this, if I do not, I need to reprogram everything from scratch again…

thanks for the reply.

13

the device 17 was the last switch I could put on the conbee2, after this i can only put light’s no more switch.

the # 17 got installed with out anny problem btw.

14

have fish soup beacous it turn the heater on of the aquaruim

Lol, I can understand.

For me it s more an inclusion not finished issue (if you have not a special new version …)
Inclusion need to be done on definitive place, but can make a try closer the gateway.

Mimixx is right, and can be usefull to see how look the device in the GUI, or at least the device json.

15

Hi every one, here a update,

after having some time in this week, I reprogram the IKEA switch and it did the same, what was different this time is that I was tired and went to bed and forgot about it til today…

I pik it up ant try it and I notice its working like normal :thinking:
I order two so i took the new one and program it and it did the same (turning all off or on), I wait for around 5 to 10 minutes it stop doing that and I was able to use it normal.

This is super strange and I will try it with a different brend that i order to check what that one would do.
best regards

Neopegasus

16

Ok with the other switch it doesn’t work with the waiting.
I will just keep checking but at least I know more where to look.

Thanks for all the help

Best regards

Neopegasus
